| Dimensions (W x D x H) |
• mm : 435 x 830 x 175
• inches : 17.1 x 32.7 x 6.9 |
| Motherboard |
| AIC Server Board Vega |
| Processor |
Processor Support :
• 5th Gen Intel® Xeon® Scalable Processors (Emerald Rapids CPU)
• 4th Gen Intel® Xeon® Scalable Processors (Sapphire Rapids CPU) |
| CPU Interconnection : 16/20GTs |
| Socket Type : Socket E1 (LGA-4677-X) |
| Chipset Support |
| Intel® C741 |
| System Memory |
• DDR5 5600/4800MHz RDIMM (1DPC)
• Total 16 memory slots; 8 slots per CPU (1DPC)
• Support up to 4TB (3DS RDIMM) |
| Front Panel |
| System power on/off, System reset, ID button |
| LEDs |
| Power status, Drive activity, LAN activity, System alert, System ID |
| Drive Bays |
| External : 3.5" hot swap x 12 |
| Internal : 2 x M.2/M-Key/2280 (PCIe Gen4) |
| Backplane(s) |
• 1 x 4-port PCIe Gen4 NVMe backplane
• 2 x 4-port SAS/SATA backplane |
| Expansion Slots |
PCIe 5.0 :
• 3 x PCIe x16 slots (HHHL)
• 1 x PCIe x8 slot (HHHL)
• 2 x PCIe x16 slots occupied by retimer cards
PCIe 4.0 :
• 8 x16 slots (FHFL)/ dual slot
• 2 x16 slots (FHHL) |
| System BIOS |
BIOS Type :
AMI UEFI BIOS |
BIOS Features :
• ACPI
• PXE
• WOL
• AC loss recovery
• IPMI 2.0 KCS mode interface
• SRIOV
• SMBIOS
• TPM
• Serial console redirection
• PCIe hot plug |
| On-board Devices |
SATA : Emmitsburg PCH on-chip solution
• 1 x Slimline connector (up to 8 SATA ports) |
IPMI :
Aspeed AST2600 Advanced PCIe Graphics & Remote Management Processor
• Baseboard Management Controller
• Intelligent Platform Interface 2.0 (IPMI 2.0)
• iKVM, Media Redirection, IPMI over LAN, Serial over LAN
• HTML5
• Redfish |
Network Controllers :
• Realtek RTL8211FS 1GbE for BMC dedicated management port
• Broadcom BCM5720 dual port 1GbE (NCSI for share NIC) |
Graphics :
• Integrated VGA support by ASPEED AST2600
• Resolution up to 1920x1200 @60Hz 32bpp |
| Front I/O |
LAN:
• 1 x RJ45 GbE connector for BMC dedicated management port
• 2 x RJ45 1GbE connectors |
USB:
4 x USB 3.1 Gen1 Type-A |
VGA
1 x DB-15 VGA connector |
|
| Power Supply |
| 2000W 3+1 redundant power supply 80+ Platinum |
| System Cooling |
| 9 x 80x56mm easy swap fans |
| System Management |
• Baseboard Management Controller
• Intelligent Platform Interface 2.0 (IPMI 2.0)
• iKVM, Media Redirection, IPMI over LAN, Serial over LAN
• SMASH Support
• HTML5
• Redfish |
| Environmental Specifications |
• Storage temperature: -10°C(14°F) ~ 60°C(140°F)
• Operating temperature: 0°C(32°F) ~ 35°C(95°F)
• Storage operating humidity: 5%~95% non-condensing |
| Gross Weight (w/PSU & Rail) |
• kgs : 71
• lbs : 156.5 |
| Packaging Dimensions (W x D x H) |
• mm : 625 x 1130 x 454
• inches : 24.6 x 44.5 x 17.9 |
| Mounting |
| Standard : 43” tool-less slide rail |
